• Azure Pipelines Service Containers and ports

    Azure Pipelines provides support for containers in several ways. You can build, run or publish Docker images with the Docker task. Container Jobs allow you to use containers to run all the tasks of a pipeline job, isolated from the host agent by the container. Finally, Service Containers provide a way to run additional containers alongside the pipeline job.

    You can see some examples of using Service Containers in the documentation, but one thing that confused me was the port mapping options - particularly with, and without Container Jobs. I ended up creating a pipeline with a number of jobs to determine the correct way to address a service container.

    You can see the full pipeline at https://github.com/flcdrg/azure-pipelines-service-containers/blob/main/azure-pipelines.yml

    I created two container resources. The first maps the container port 1443 to port 1443 on the host, whereas the second assigns a random mapped port on the host.

        - container: mssql
          image: mcr.microsoft.com/mssql/server:2019-latest
            - 1433:1433
            ACCEPT_EULA: Y
            SA_PASSWORD: yourStrong(!)Password
        - container: mssql2
          image: mcr.microsoft.com/mssql/server:2019-latest
            - 1433
            ACCEPT_EULA: Y
            SA_PASSWORD: yourStrong(!)Password

    These are mapped as service containers in each job by one of the following:

        mssqlsvc: mssql

    which maps the container to port 1443 on the host, or

        mssqlsvc: mssql2

    which maps to a random port on the host.

    I then figured out what was the correct way to connect to the container. In my case (using a SQL Server image) I’m using the sqlcmd command line utility.

    Here are the results of my experiment:

    Regular job, local process

    A regular (non-container) Azure pipelines job, relying on sqlcmd being preinstalled on the host.

    sqlcmd -S localhost

    Regular job, inline Docker container

    We’re running a separate Docker container in a script task. To allow this container to be able to connect to our service container, we ensure they’re both running on the same network.

    network=$(docker network list --filter name=vsts_network -q)
    docker run --rm --network $network mcr.microsoft.com/mssql-tools /opt/mssql-tools/bin/sqlcmd -S mssqlsvc

    Regular job, local process, random port

    The host-mapped port has been randomly selected, so we need to use a special variable to obtain the actual port number. The variable name takes the form agent.services.<serviceName>.ports.<port>.

    In our case, the <serviceName> corresponds to the left-hand name under the services: section and the <port> corresponds to the port number back up in the - ports: section of the resource container declaration.

    sqlcmd -S tcp:localhost,$(agent.services.mssqlsvc.ports.1433)

    Regular job, inline Docker container, random port

    The random port can be ignored, as we connect directly to the SQL container, not via the host-mapped port.

    network=$(docker network list --filter name=vsts_network -q)
    docker run --rm --network $network mcr.microsoft.com/mssql-tools /opt/mssql-tools/bin/sqlcmd -S mssqlsvc

    Container job, local process

    A Container job means we’re already running inside a Docker container. (The image used for the container job has sqlcmd installed in /opt/mssql-tools18/bin).

    /opt/mssql-tools18/bin/sqlcmd -S mssqlsvc

    Container job, inline Docker container

    So long as the Docker container created in the script task is on the same network, it’s similar

    network=$(docker network list --filter name=vsts_network -q)
    docker run --rm --network $network mcr.microsoft.com/mssql-tools /opt/mssql-tools/bin/sqlcmd -S mssqlsvc

    Container job, local process, random port

    Because we’re in the container job, we ignore the random port

    /opt/mssql-tools18/bin/sqlcmd -S mssqlsvc

    Container job, inline Docker container, random port

    And the same for an ‘inline’ container

    network=$(docker network list --filter name=vsts_network -q)
    docker run --rm --network $network mcr.microsoft.com/mssql-tools /opt/mssql-tools/bin/sqlcmd -S mssqlsvc

  • Converting Azure Pipelines Variable Groups to YAML

    If you’ve been using Azure Pipelines for a while, you might have made use of the Variable group feature (under the Library tab). These provide a way of defining a group of variables that can be referenced both by ‘Classic’ Release pipelines and the newer YAML-based pipelines.

    variable group in the Azure DevOps Pipelines UI

    You might get to a point where you realise that a lot of the variables being defined in variable groups would be better off being declared directly in a YAML file. That way you get the benefit of version control history. Obviously, you wouldn’t commit any secrets in your source code, but other non-sensitive values should be fine. Secrets are better left in a variable group, or better yet as an Azure Key Vault secret.

    I came up with the following PowerShell script that makes use of the Azure CLI commands to convert a variable group into the equivalent YAML syntax.

    param (
    $ErrorActionPreference = 'Stop'
    # Find id of group
    $groups = (az pipelines variable-group list --organization "https://dev.azure.com/$Organisation" --project "$Project") | ConvertFrom-Json
    $groupId = $groups | Where-Object { $_.name -eq $GroupName } | Select-Object -ExpandProperty id -First 1
    $group = (az pipelines variable-group show --id $groupId --organization "https://dev.azure.com/$Organisation" --project "$Project") | ConvertFrom-Json
    $group.variables | Get-Member -MemberType NoteProperty | ForEach-Object {
        if ($Array.IsPresent) {
            Write-Output "- name: $($_.Name)"
            Write-Output "  value: $($group.variables.$($_.Name).Value)"
        } else {
            Write-Output "  $($_.Name): $($group.variables.$($_.Name).Value)"

    The script is also in this GitHub Gist.

    If I run the script like this:

    .\Convert-VariableGroup.ps1 -Organisation gardiner -GroupName "My Variable Group" -Project "GitHub Builds"

    Then it produces:

    And_More: $(Another.Thing)
    Another.Thing: Another value
    Something: A value

    If I add the -Array switch, then the output changes to:

    - name: And_More
      value: $(Another.Thing)
    - name: Another.Thing
      value: Another value
    - name: ASecret
    - name: Something
      value: A value

    Note that the variable which was marked as ‘secret’ doesn’t have a value.
